It has a high-cost performance ratio and is the preferred choice for low-cost conveyor belts.
High tensile strength
Less stretch
High adhesion
Excellent troughability
High impact resistance
| EE fabric | Executive standards | Unit | EE 80 | EE 100 | EE 125 | EE 150 | EE 160 | EE 200 | ||||||
| Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | |||
| Material | - | Warp：Polyester Yarn Weft：Polyester Yarn | ||||||||||||
| Breaking Strength | GB/T 31334.5-2017 | N/cm | ≥1050 | ≥400 | ≥1300 | ≥500 | ≥1600 | ≥550 | ≥1900 | ≥700 | ≥2100 | ≥700 | ≥2400 | ≥800 |
| Elongation at Break | GB/T 31334.5-2017 | % | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 |
| Hot Air Shrinkage (150℃, 30min) | GB/T 31334.1-2015 | % | ≤4.0 | ≤0.5 | ≤4.0 | ≤0.5 | ≤4.0 | ≤0.5 | ≤4.0 | ≤0.5 | ≤4.0 | ≤0.5 | ≤4.0 | ≤0.5 |
| Peel Adhesion | GB/T 31334.4-2017 | N/mm | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ||||||
Weight Density | GB/T 31334.6-2020 | g/m2 | 320±20 | 360±20 | 430±20 | 520±20 | 560±20 | 630±30 | ||||||
| Thickness | GB/T 31334.6-2020 | mm | 0.45±0.05 | 0.50±0.05 | 0.60±0.05 | 0.75±0.05 | 0.75±0.05 | 0.82±0.10 | ||||||
| Width range | GB/T 31334.6-2020 | mm | 500~3100 | |||||||||||
| EE fabric | Executive standards | Unit | EE 250 | EE 300 | EE 350 | EE 400 | EE 450 | EE 500 | ||||||
| Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | |||
| Material | - | Warp：Polyester Yarn Weft：Polyester Yarn | ||||||||||||
Breaking Strength | GB/T 31334.5-2017 | N/cm | ≥3000 | ≥850 | ≥3400 | ≥850 | ≥3900 | ≥900 | ≥4500 | ≥900 | ≥5000 | ≥950 | ≥5600 | ≥1000 |
| Elongation at Break | GB/T 31334.5-2017 | % | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 |
| Hot Air Shrinkage (150℃, 30min) | GB/T 31334.1-2015 | % | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 |
| Peel Adhesion | GB/T 31334.4-2017 | N/mm | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ||||||
| Weight Density | GB/T 31334.6-2020 | g/m2 | 790±30 | 880±30 | 1050±40 | 1200±50 | 1250±50 | 1400±50 | ||||||
| Thickness | GB/T 31334.6-2020 | mm | 1.05±0.10 | 1.10±0.12 | 1.25±0.12 | 1.50±0.15 | 1.60±0.15 | 1.80±0.20 | ||||||
| Width range | GB/T 31334.6-2020 | mm | 500~3100 | |||||||||||
| Remarks | Our company can produce according to the specifications and indicators required by customers. | |||||||||||||
Dipped fabric is a kind of ideal rubber framework material. It is widely used in producing conveyor belts, V-belts, rubber hoses, escalator handrails, rubber tracks, rail transportation cushion, submarine pipe, soft oil tank, etc.
